Svelte Types Generator

Generate Svelte types for custom elements and web components

This package generates TypeScript declarations for custom elements used in Svelte projects. The declarations provide type-safe validation for component attributes, component properties, custom events, and CSS custom properties.

Types are generated from a Custom Elements Manifest and include documentation for:

Custom elements and component descriptions
Attributes and properties
Component properties passed through Svelte attributes
Custom event handlers with Svelte’s on: syntax
Global element properties and optional DOM event handlers
Methods, slots, CSS parts, CSS states, and CSS custom properties

Usage

The generator supports build scripts and the Custom Elements Manifest Analyzer.

Install

npm install --save-dev @wc-toolkit/svelte-types

Build Pipeline

import {
  generateSvelteTypes,
  type SvelteTypesOptions,
} from "@wc-toolkit/svelte-types";
import manifest from "./custom-elements.json";

generateSvelteTypes(manifest, {
  outdir: "./src",
  fileName: "custom-elements-svelte.d.ts",
});

Custom Elements Manifest Analyzer

First install and configure the analyzer and create a manifest configuration file.

import { customElementSveltePlugin } from "@wc-toolkit/svelte-types";

export default {
  plugins: [
    customElementSveltePlugin({
      outdir: "./src",
      fileName: "custom-elements-svelte.d.ts",
    }),
  ],
};

Include the Generated Types

The generated file augments svelteHTML.IntrinsicElements. Include it in the TypeScript project used by your Svelte application.

Option 1: Include the File

Write the file somewhere covered by tsconfig.json:

{
  "include": [
    "src/**/*.ts",
    "src/**/*.svelte",
    "src/custom-elements-svelte.d.ts"
  ]
}

Option 2: Configure TypeScript Types

If the declaration is published by a package, add its type entry to tsconfig.json:

{
  "compilerOptions": {
    "types": ["my-library/custom-elements-svelte"]
  }
}

Use the generated declarations directly in Svelte markup:

<script lang="ts">
  let value = "";

  function handleChange(event: CustomEvent) {
    console.log(event.detail);
  }
</script>

<x-input
  label="Name"
  value={value}
  on:change={handleChange}
/>

Svelte Features

Component Properties

Public component properties are emitted as typed component attributes. This is the valid way to pass values to lowercase custom elements in Svelte:

<x-slider value={value} />

Read-only and static properties are excluded. When a CEM property is associated with an attribute, it is emitted once using the attribute name.

Custom Events

Manifest events are available through Svelte’s event directive syntax:

<x-input
  on:change={(event) => {
    console.log(event.detail);
  }}
/>

By default, Svelte 5 event attributes are generated alongside legacy event directives:

<x-button on:change={handleChange} />
<x-button onchange={handleChange} />

For a manifest event typed as CustomEvent<ChangeDetail>, both generated handlers accept that event type. Non-custom event types from the manifest are preserved, such as MouseEvent.

CSS Custom Properties

CSS custom properties from the manifest are generated as Svelte style directives and accept string | number values:

<x-slider style:--track-color={trackColor} />

Slots

Use web component slots with Svelte’s standard slot attribute:

<x-card>
  <span slot="title">Card title</span>
  Card content
</x-card>

Refs and Methods

The generator exports a *Element type for each component. Use it with Svelte’s bind:this to access the custom element and call its methods:

<script lang="ts">
  import type { DialogElement } from "./types/custom-elements-svelte";

  let dialog: DialogElement;

  function openDialog() {
    dialog.showModal();
  }
</script>

<x-dialog bind:this={dialog} />
<button onclick={openDialog}>Open</button>

The exact ref type depends on the custom element class exported by the component library.

Named CEM slots also produce a slot-name union for application code:

import type { CardSlots } from "./types/custom-elements-svelte";

const slotName: CardSlots = "header";

Configuration Options

Output Options

Option	Type	Default	Description
`fileName`	`string`	`custom-elements-svelte.d.ts`	Name of the generated declaration file. Omit it to return declaration text without writing a file.
`outdir`	`string`	`./`	Directory where the generated declaration file is written.
`exclude`	`string[]`	`[]`	Component class names to exclude.

Import Options

Option	Type	Description
`componentTypePath`	`(name: string, tag?: string, modulePath?: string) => string`	Returns the module path used to import each component class. The third argument is the component’s source module path from the manifest.
`globalTypePath`	`string`	Imports all component classes and named event detail types from one module.

When neither import option is configured, types are read directly from the manifest. Generated imports expect named component exports:

import type { XButton } from "my-library/components/x-button/x-button.js";

Event Options

Option	Type	Default	Description
`globalEvents`	`string`		Adds custom event declarations to every generated component type.
`includeDefaultDOMEvents`	`boolean`	`false`	Adds common DOM event handlers such as `on:click`, `onclick`, `on:focus`, and `onfocus`.
`includeModernEventHandlers`	`boolean`	`true`	Includes Svelte 5 event attributes such as `onclick` alongside legacy `on:` handlers. Set to `false` for legacy syntax only.

{
  globalEvents: `
    /** Fired when application telemetry is recorded. */
    "on:telemetry"?: (event: CustomEvent<TelemetryDetail>) => void;
  `,
  includeDefaultDOMEvents: true,
  includeModernEventHandlers: true,
}

Manifest and Utility Options

Option	Type	Default	Description
`typesSrc`	`string`	`type`	Reads types from an alternate CEM property, such as `parsedType`.
`tagFormatter`	`(tagName: string) => string`		Formats tag names before adding them to `CustomElements`.
`skip`	`boolean`	`false`	Prevents generation when `true`.
`debug`	`boolean`	`false`	Enables generator logs.
`componentDescriptionOptions`	`ComponentDescriptionOptions`		Configures component documentation and API order in the generated declarations.

Complete Configuration Example

import { generateSvelteTypes } from "@wc-toolkit/svelte-types";
import manifest from "./custom-elements.json";

generateSvelteTypes(manifest, {
  fileName: "custom-elements-svelte.d.ts",
  outdir: "./src/types",
  exclude: ["InternalComponent"],
  componentTypePath: (name, tagName) =>
    `my-library/components/${tagName}/${tagName}.js`,
  globalEvents: `
    "on:telemetry"?: (event: CustomEvent<TelemetryDetail>) => void;
  `,
  includeDefaultDOMEvents: true,
  typesSrc: "parsedType",
  tagFormatter: (tagName) => tagName.toLowerCase(),
  componentDescriptionOptions: {
    descriptionSrc: "summary",
  },
  debug: process.env.DEBUG === "true",
  skip: false,
});

For more information about this package and other Web Component tools, visit the WC Toolkit website.
